THREE.JS使用TransformControls对模型拖拽的代码实例

一、原理:

TransformControls 是由 THREE.JS 提供的一类控制器。

该类可提供一种类似于在数字内容创建工具(例如Blender)中对模型进行交互的方式,来在3D空间中变换物体。和其他控制器不同的是,变换控制器不倾向于对场景摄像机的变换进行改变。

详见官网。

二、步骤:

初始化场景
引入TransformControls控制器,并对其进行监听
添加模型和连线
根据控制器的改变对连线进行修改

三、代码:

<template>
  <div class="fa_container">
    <div class="container" ref="container"></div>
  </div>
</template>

<script>
import * as THREE from 'three'
import { OrbitControls } from 'three/examples/jsm/controls/OrbitControls'
import { TransformControls } from 'three/examples/jsm/controls/TransformControls.js'

const scene = new THREE.Scene()
let renderer = new THREE.WebGLRenderer({
  antialias: true,
  alpha: true,
  logarithmicDepthBuffer: true
})
let camera, controls, transformControl

const pointer = new THREE.Vector2()
const point = new THREE.Vector3()
const raycaster = new THREE.Raycaster()
let splineHelperObjects = []
const ARC_SEGMENTS = 200
let splines = []

export default {
  name: 'model',
  data () {
    return {
      positionList: [
        [10, 0, 0],
        [-10, 0, 0]
      ]
    }
  },
  mounted () {
    this.init()
    this.addMarkModel()
    this.render()
  },

  methods: {
    init () {
      this.dom = this.$refs['container']

      this.initHelper()
      this.initLight()
      this.initCamera()
      this.initRender()
      this.initControls()

      this.dom.addEventListener('pointermove', e => {
        this.onPointerMove(e)
      })
    },
    initHelper () {
      scene.background = new THREE.Color(0xf0f0f0)

      // const axes = new THREE.AxesHelper(50)
      // scene.add(axes)

      const planeGeometry = new THREE.PlaneGeometry(2000, 2000)
      planeGeometry.rotateX(-Math.PI / 2)
      const planeMaterial = new THREE.ShadowMaterial({ color: 0x000000, opacity: 0.2 })
      const plane = new THREE.Mesh(planeGeometry, planeMaterial)
      plane.position.y = -200
      plane.receiveShadow = true
      scene.add(plane)

      const helper = new THREE.GridHelper(2000, 100)
      helper.position.y = -199
      helper.material.opacity = 0.25
      helper.material.transparent = true
      scene.add(helper)
    },
    initCamera () {
      camera = new THREE.PerspectiveCamera(
        45,
        this.dom.offsetWidth / this.dom.offsetHeight,
        0.001,
        10000
      )
      camera.position.set(35, 35, 35)
    },
    initLight () {
      const directLight = new THREE.DirectionalLight('#ffffff', 0.5)
      const directLight1 = new THREE.DirectionalLight('#ffffff', 0.5)
      const directLight2 = new THREE.PointLight('#ffffff', 0.5)
      const ambientLight = new THREE.AmbientLight('#ffffff', 0.3)

      directLight.castShadow = true
      directLight.position.set(15, 15, 15)
      directLight1.position.set(-15, -15, 15)
      ambientLight.position.set(0, 0, -5)
      directLight2.position.set(-15, 15, -15)
      directLight2.castShadow = true

      scene.add(directLight, directLight1, ambientLight, directLight2)
    },
    initRender () {
      renderer.setSize(1902, 935)
      renderer.outputEncoding = THREE.sRGBEncoding
      this.dom.appendChild(renderer.domElement)
    },
    initControls () {
      controls = new OrbitControls(camera, renderer.domElement)

      transformControl = new TransformControls(camera, renderer.domElement)
      transformControl.addEventListener('change', () => {
        console.log('模型拖动')
      })
      transformControl.addEventListener('dragging-changed', function (event) {
        controls.enabled = !event.value
      })

      transformControl.addEventListener('objectChange', param => {
        this.updateSplineOutline()
      })
      scene.add(transformControl)
    },

    // 鼠标移动
    onPointerMove (event) {
      pointer.x = (event.clientX / window.innerWidth) * 2 - 1
      pointer.y = -(event.clientY / window.innerHeight) * 2 + 1

      raycaster.setFromCamera(pointer, camera)

      const intersects = raycaster.intersectObjects(splineHelperObjects, false)

      if (intersects.length > 0) {
        const object = intersects[0].object

        if (object !== transformControl.object) {
          transformControl.attach(object)
          controls.enabled = false
        }
      }
    },
    // 更新连线
    updateSplineOutline () {
      for (let k = 0; k < splines.length; k++) {
        const spline = splines[k]
        const splineMesh = spline.mesh
        const position = splineMesh.geometry.attributes.position
        for (let i = 0; i < ARC_SEGMENTS; i++) {
          const t = i / (ARC_SEGMENTS - 1)
          spline.getPoint(t, point)
          position.setXYZ(i, point.x, point.y, point.z)
        }
        position.needsUpdate = true
      }
    },
    render () {
      requestAnimationFrame(this.render.bind(this))
      controls.update()
      renderer.render(scene, camera)
    },

    addMarkModel () {
      for (let i = 0; i < this.positionList.length; i++) {
        let position = []

        let obj1 = this.creatSpot(this.positionList[i], i)
        let obj2 = this.creatHtml(i)

        setTimeout(() => {
          position.push(obj1.position)
          position.push(obj2.position)
          this.creatLine(position)
        }, 2000)
      }
    },
    creatSpot (positionArr, index) {
      const spherGeometry = new THREE.SphereGeometry(3, 32, 16)
      const spherMaterial = new THREE.MeshLambertMaterial({ color: 'red' })
      const sphere = new THREE.Mesh(spherGeometry, spherMaterial)
      sphere.position.set(positionArr[0], positionArr[1], positionArr[2])
      sphere.scale.set(0.2, 0.2, 0.2)
      splineHelperObjects.push(sphere)
      scene.add(sphere)
      return sphere
    },
    creatHtml (index, spot) {
      const spherGeometry = new THREE.BoxBufferGeometry(15, 15, 15)
      const spherMaterial = new THREE.MeshPhongMaterial({
        transparent: true,
        opacity: 1,
        color: 'green'
      })
      const sphere = new THREE.Mesh(spherGeometry, spherMaterial)

      sphere.position.x = Math.random() * 10
      sphere.position.y = Math.random() * 20
      sphere.position.z = Math.random() * 15
      sphere.scale.set(0.2, 0.2, 0.2)
      splineHelperObjects.push(sphere)
      scene.add(sphere)

      return sphere
    },
    creatLine (position) {
      var curve = new THREE.CatmullRomCurve3(position)
      var points = curve.getPoints(ARC_SEGMENTS)
      var geometry = new THREE.BufferGeometry().setFromPoints(points)
      var material = new THREE.LineBasicMaterial({ color: 0xff0000 })

      curve.mesh = new THREE.LineSegments(geometry, material)
      scene.add(curve.mesh)
      splines.push(curve)
    }
  }
}
</script>

<style>
.container {
  width: 1902px;
  height: 935px;
  overflow: hidden;
  background: black;
  display: inline-block;
}

</style>
